HKS GTIII-RS Turbo (14001-AK032)

Description

GTIII-RS A/R0.75 WG TURBINE









【Features】

• Highly reliable MHI high performance CHRA.
• Compatible with GTII 7460, 8262, GT2835, and 3037 series.
• Recommended engine output range is between 340HP (250kw) and 480HP (353kw).
• Compressor housing suction diameter is 100mm, and outlet diameter is 49mm.
• Turbine inlet flange is T25, and outlet flange is 4-bolt 64mm flange.
• Installation size of the oil port and water cooling port is slightly different between GTII 7460, 8262,
• GT2835, and 3037 series and GTIII-RS. Simple modification is required.





【Engine Output】



Test Vehicle：SILVIA/SR20DET

• HKS METAL HEAD GASKET 1.2mm
• HKS CAMSHAFT STEP1 256°
• HKS SUPER POWER FLOW
• HKS MUFFLER
• EVC (Boost 1.5㎏f/cm²)

1）GTIII-RS ：481.9ps(354kw)
2）GTII7460：451.4ps(332kw)





【Note】

• The graph above shows the result of in-house testing.
  The actual results may vary depending on each vehicle’s specification(s).
